68140628AE DODGE JOURNEY LHD Hydraulic Power Steering gear

68140628AE DODGE JOURNEY  LHD Hydraulic Power Steering Gear

Composition of DODGE JOURNEY Power Steering System

The DODGE JOURNEY power steering system is a whole composed of multiple key components working together. Its main components include:

    ● Steering oil tank: stores and supplies hydraulic oil to ensure the continuous and stable operation of the hydraulic system.

    ● Hydraulic steering pump: driven by the engine to provide the required hydraulic pressure for the steering system.

    ● Steering column: connects the steering wheel and steering gear to realize the driver's steering input.

    ● Power steering gear: responsible for converting hydraulic energy into mechanical power to achieve easy steering operation.

The 68140628AE DODGE JOURNEY LHD steering gear is made of high-quality materials to ensure its durability and reliability, and can maintain excellent performance even in harsh road conditions.

68140628AE Working principle of DODGE JOURNEY steering gear

68140628AE The core principle of DODGE JOURNEY steering gear is to use the power provided by the engine to amplify the force applied by the driver on the steering wheel through the hydraulic system, thereby reducing the physical resistance of steering and making driving easier and smoother. The specific working process is as follows:

    ● Hydraulic pump oil supply: The engine drives the hydraulic pump to draw the steering hydraulic oil from the oil tank and pressurize it to the power steering gear.

    ● Control valve adjusts oil pressure: The control valve is connected to the steering shaft and can adjust the oil flow direction according to the rotation of the steering wheel to ensure that the appropriate amount of hydraulic pressure is transmitted to the inside of the steering gear.

    ● Power-assisting effect: After the oil enters the power cylinder, it pushes the piston, so that the pinion applies additional auxiliary force to the rack, thereby reducing the force required by the driver when steering.

    ● Backflow and reset: When the steering wheel is returned to the center, the control valve returns to the neutral position, and the excess hydraulic oil returns to the oil tank to ensure the smooth operation of the system.

This power steering system can not only provide precise steering assistance, but also reduce driving fatigue and improve driving safety.

DODGE JOURNEY steering gear installation and adaptability

68140628AE DODGE JOURNEY  steering gear is suitable for DODGE JOURNEY  left-hand drive models (LHD). For specific compatible models, please refer to the DOUDGE official technical manual or consult a professional technician. During the installation process, you need to pay attention to the following points:

    ● Ensure that the hydraulic oil matches: Use the hydraulic oil recommended by the original manufacturer to avoid system failure due to oil incompatibility.

    ● Correctly connect the hydraulic pipeline: During installation, you need to ensure that the oil pipe is tightly connected to avoid leakage.

    ● Calibrate the steering system: After replacing the steering gear, it is recommended to perform a four-wheel alignment to ensure steering accuracy.

Proper installation and maintenance can effectively extend the service life of the DODGE steering gear and keep it in optimal working condition.
